Aluminum door and window hinge drilling machine ARK-JLZ-1800

Application and structural features:

It is mainly used for processing friction hinge mounting holes on aluminum alloy and plastic steel door and window materials, which provides reliable guarantee for ensuring the processing accuracy of mounting holes on both sides and improving work efficiency;

8-10 holes can be processed at the same time in one clamping, and the hole spacing and hole processing height position adjustment are simple and fast. Imported precision bearings are used in key parts, which have the characteristics of high processing accuracy, stable performance and long life;

This machine is easy to operate and has a high degree of automation. It is one of the main equipment for door and window manufacturers to improve work efficiency.

Main technical parameters:

Drilling diameter: Φ3—Φ11mm

Drilling distance: 20--220mm

Motor power: 2×1.5Kw

Power supply: 380V/50Hz

Air pressure: 0.5～0.6MPa

Machine tool overall dimensions (length×width×height): 3500×620×1200mm

Weight: 600kg
